Coating Business
UV Coating Agent
UV Blocking Coating Agent
Blue Light Cut
| Coating Type | Viscosity | Pencil Hardness | Transmittance | Water Contact Angle |
|---|---|---|---|---|
| Roll coating / Flow coating | 4~10 cP | Varies depending on HB~4H description | 380nm ≤ 1% 450nm ≤ 50% |
100~110˚ |
Anti-Fingerprint & Scratch Prevention Coating Agent
Anti Finger Print & High-Scratch Resistance
| Coating Type | Viscosity | Pencil Hardness | Transmittance | Scratch Resistance (Steel Wool #0000) | Water Contact Angle |
|---|---|---|---|---|---|
| Flow coating | 4~10 cP | Varies depending on HB~4H description | 90~92% | 1,000~5,000 times Load 1kgf |
105±5 |
| Roll coating | 4~10 cP | Varies depending on HB~4H description | 90~92% | 1,000~5,000 times Load 1kgf |
105±5 |
UV-Hardening Patterned Resins, AdhesivesSolvent-Free resin
UV Molding
| Coating Type | Viscosity | Pencil Hardness | Transmittance |
|---|---|---|---|
| For UV molding | 400~1,000 cP | Varies depending on H~4H material | 98% |
UV-Hardening Colored Patterned Resins
Color UV Imprinting Pattern Ink
Furniture VCM-oriented paint currently in mass production and market application
Hyundai Venue Tail lamp film is manufactured through a pattern process (black design part) and then attached to the injection molded product
Coating agent for molding processing
Easy Forming
| Coating Type | Viscosity | Pencil Hardness | Transmittance | Contact Angle | Thermoforming Angle |
|---|---|---|---|---|---|
| Flow coating | 4~10 cP | Varies depending on H~4H description | 90~92% | 100~105˚ | 2.0R |
Coating agent for molding processing
| Product Name | Product Specification | Solid Content | Hardness |
|---|---|---|---|
| Hard Coating | General UV hard coating agent with hardness of HB, 4H, and H or more secured for PC, PMMA, and PET, respectively | 20~98% | HB~4H |
| Anti-Fog | Anti-fog effect lasting for six months or longer | 20~58% | HB |
| Anti-Glare |
Coating agent to create matte effect by causing diffuse reflection Haze : 5~40% |
15~50% | HB~4H |
| Anti-Static |
Coating agent with conducting polymer to form surface resistance on various surfaces ; Surface resistance : 10^6~10^8 Ω ,10^9~10^11 Ω ; Applicable materials – PMMA/PC/PET/ABS/PVC |
10~50% | B~3H |
| Anti-Pollution | Coating agent to prevent surface pollution by creating contact angle on product surface at 100˚–110˚ | 30~50% | HB~4H |
| UV Molding Solvent-Free Coating Agent |
Solvent-free coating agent available as soft or hard type | 98% ~ | |
| UV-Hardening Primer |
Primer coating agent to improve offset printability on product surface | 15~40% | |
| High-Hardness Coating |
High-hardness coating agent to substitute tempered glass | 15~40% | 8H~9h |
| Adhesive | Adhesive between PMMA or PC products | 98% ~ | |
| Scratch Restoration |
Coating agent for self-restoration of scratched surfaces | 20~58% | 3H ~ |
* Please inquire for formability as it varies by material.
